Speedo Gear Shaft Seal LandCruiser 40 60 70 75 78 79 80 Series Hilux

Speedometer drive gear shaft seal to suit Toyota LandCruiser and Hilux models.

Prevents oil leaks from the speedo drive housing on gearbox or transfer case.



This seal is fitted to the speedometer drive gear housing, where the speedo cable or sender enters the gearbox or transfer case.



Its job is to:



• Seal around the speedo gear shaft
• Prevent gearbox or transfer oil from leaking
• Keep dirt and contaminants out





These seals sit in the speedo drive housing and are exposed to oil and heat over time.









What it actually does





• Stops oil leaking from the speedo drive
• Maintains correct oil level in gearbox/transfer
• Prevents contamination entering the housing





A worn seal is a common cause of:



• Oil weeping down the side of gearbox
• Wet speedo cable area
• Slow oil loss over time





Speedo drive seals are a known service item on older Toyota drivetrains and are used across multiple LandCruiser and Hilux models.









Vehicle Compatibility





Toyota LandCruiser:



• 40 Series (11/1978 onwards)
• 60 Series
• 70 / 75 / 78 / 79 Series
• 80 Series





Also suits:



• Hilux (multiple models)
• 4Runner





(Used across a wide range of Toyota manual gearbox and transfer setups)









Common Questions





Where is this located?

On the gearbox or transfer case where the speedo cable or sensor connects.



Is this a common leak point?

Yes — very common on older LandCruisers.



Is this the same as an O-ring?

No — this is the shaft seal inside the housing (different to outer O-ring).



When should it be replaced?

When leaking, or anytime the speedo gear is removed.

Terrain Tamer Speedometer Drive Gear Housing Seal suitable for Toyota Landcruiser Hilux & 4Runner



This is a new quality Terrain Tamer brand Speedo Drive Gear Housing Seal

Suitable for:

- Toyota Landcruiser 40 series, BJ40, BJ42, FJ40, FJ45, FJ55, HJ45, HJ47, built from 11/1978 to 11/1984 runout.

- Toyota Landcruiser 60 series, FJ60,, FJ62 HJ60, HJ61, built from 1980 to 1990 runout.

- Toyota Landcruiser 70 series and Bundera, LJ70, RJ70, BJ70, BJ73, BJ74, FJ70, FJ73, FJ75, HJ75, FZJ70, FZJ73, FZJ75, HZJ70, HZJ70, HZJ75, HZJ78, HZJ79, PZJ70, PZJ73,built from 11/1984 to 12/2006 runout.

- Toyota Landcruiser 80 series, FJ80, FZJ80, HZJ80, HDJ80, built from 01/1990 to 12/1997 runout.

- Toyota Hilux LN30, LN40, LN46, RN30, RN31, RN36, RN46, LN55, LN56, LN60, LN61, LN65, YN55, YN56, YN57, YN58, YN60, YN63, YN65, YN67, LN85, LN86, RN85, YN85, YN86, LN106, LN107, LN111, RN105, RN106, RN110, YN130, LN130, RN130, VZN130, built to 08/1997 runout.

- Toyota Hilux KZN165, LN147, LN152, LN167, LN172, RZN147, RZN149, RZN154, RZN169, RZN174, VZN167, VZN172, built from 08/1997 to 12/2004 runout.
