Package Deal for ScanGauge-II and Window Mount

ScanGauge II effectively monitors your vehicle and provides real-time information crucial to manage your vehicle. Incorporates well over 15 digital gauges, trip data consisting of 5 sets as well as a simple Scan Tool whose main function is to bring alert to you of any set and pending trouble codes.

ScanGauge II is a plug and play, easy to use vehicle monitor. Just plug the OBDII cable into the OBD port and its ready to work. It works on any car with a compatible OBDII/EOBD and CAN protocols.

For the ultimate in-vehicle performance and fuel economy monitoring you can run multiple ScanGauges units by daisy chain them!

Auto Digital Gauges

The ScanGauge-II can display up to 4 digital gauges at one time. The gauges are updated in real-time, as you drive.

You can change the unit of measure between standard and metric

• Fuel Economy
• Fuel Rate
• Digital Speedometer Adjustable for the size of gearing changes
• Manifold Pressure (not available on some vehicles
• Battery Voltage
• Engine Coolant Temp
• Intake Air Temp
• Engine Load
• Ignition Timing
• Throttle Position
• Open/Closed Loop
• Tacho-Meter
• And More!

Car Trip Computers

Five built-in trip computers keep track of everything from fuel cost to distance traveled and everything in between.

The TRIP modes in the ScanGauge can be used to save fuel. Improved driving habits can improve fuel economy by up to 30%.

The ScanGauge-II lets you try different driving techniques and routes and gives quick feedback on how they affect fuel use. TANK Trip which you reset when you fill up the tank. It can provide you with “to empty” data as well as other useful information.

• Fuel Economy
• Fuel Used and Cost
• Maximum Coolant Temp
• Distance
• Maximum RPM
• Drive Time
• Maximum Speed
• Average Speed
• Total CO2
• Current Tank of Fuel information : Distance to Empty / Time to Empty / Fuel to Empty

OBDII Engine Diagnostic Scan Tool

ScanGauge-II Can display Diagnostic trouble code, tells you how many there are and the Trouble Codes themselves. Data captured when the Trouble Code was set can be recalled to help troubleshoot the problems.

• Reads Trouble Codes
• Clears Trouble Codes
• Shows Conditions When Trouble Was Detected (RPM, COOLANT, TEMP etc)
• Turns Off “CHECK ENGINE” Lamp
• Shows When Onboard Tests Have Been Completed And Vehicle Is Ready To Pass OBDII emissions Testing

​ScanGauge-2 Exclusive Features

The ScanGauge-II features the exclusive X-GAUGE™ programmable gauge system. The X-Gauge™ gives you the ability to customise your ScanGauge-II by adding additional vehicle specific digital gauges to monitor parameters such as Transmission Temperature, Trip Data and Fuel Economy information.

The Performance Monitor™ allows you to measure and record performance data. You can designate a specific digital gauge to record as well as save and recall the data of up to 8 performance runs for later review and comparison. Performance Monitor lets you step through performance run data by key increments of time, speed and distance giving you a clear picture of your vehicle’s performance.

SG2 Features

NON-VOLATILE MEMORY(stored information is not lost when disconnected)

• User settings automatically saved
• Up to 10 user commands can be stored and recalled
• Today, Yesterday and Tank Trip data automatically saved
• Vehicle settings automatically saved

EASY INSTALLATION

• No Tools Required!
• Cable detachable at the ScanGauge
• Easily move from vehicle to vehicle
• ScanGauge Compact Size
• Size 3.6"W x 1.4"H x 1"D

EASY TO OPERATE

• Simple on-screen operation
• 4 menu driven soft keys
• User settable update rate (Slow, Normal and Fast)
• A HOME key to quickly return to the start screen

USER SETTABLE BACKLIGHT

• Display Colour, 7 Standard screen colours and a custom setting with 63 possible colours.
• Backlight for night use
• User settable Off, Low and High

AUTOMATIC POWER CONTROL

• Automatic delayed power-down after engine shutoff
• Automatic power-up when engine is started
• Manual power-up with delayed power-down via HOME key
