NSK Timing Belt Idler – LandCruiser 1HZ / 1HD – Replaces Toyota 13505-17020

NSK Timing Belt Idler – LandCruiser 1HZ / 1HD – Replaces Toyota 13505-17020

Regular price $123.75 Sale

NSK timing belt idler pulley for selected Toyota LandCruiser 1HZ, 1HD-FT and 1HD-FTE diesel applications using the hydraulic timing belt tensioner system.

  • Brand: NSK
  • NSK part number: 62TB0629B29
  • Toyota OE reference: 13505-17020
  • Quantity: 1 idler assembly

What you are buying: This is an NSK-branded Japanese timing belt idler, supplied in NSK packaging. It cross-references Toyota Genuine part number 13505-17020, but it is not supplied in Toyota Genuine packaging.

Typical Fitment

  • LandCruiser HZJ75 – late 1HZ hydraulic-tensioner applications
  • LandCruiser HZJ78 / HZJ79 – 1HZ hydraulic-tensioner applications
  • LandCruiser HZJ105 – 1HZ
  • LandCruiser HDJ80 – 1HD-FT
  • LandCruiser HDJ78 / HDJ79 / HDJ100 – selected 1HD-FTE applications

Important: Early 1HZ engines using the spring-tensioner timing belt arrangement use different components. If your vehicle is near a production change, confirm the existing part number or contact us with your VIN/chassis number.

Prefer Toyota Genuine? View the Genuine Toyota 13505-17020 timing belt idler. These are alternatives for the same OE-reference application — you only need one idler.
