Suitable for:
- Toyota Hilux KZN165, fitted with the 1KZTE 3.0 litre 4 cylinder turbo diesel engine, built from 09/1999 to 01/2005 runout.
- Toyota Hilux Surf, KZN185, fitted with the 1KZTE 3.0 litre 4 cylinder turbo diesel engine, built from 11/1995 to 07/2000.
- Toyota Hilux KUN16, 2WD, KUN26, 4WD,fitted with the 1KDFTV 3.0 litre 4 cylinder Common Rail D4D turbo diesel engine, built from 08/2004 to 03/2015 runout.
(with 2 piece water pump assembly modification)
- Toyota Prado 90, 95, 120, Series, KZJ95, KZJ120, fitted with the 1KZTE 3.0 litre 4 cylinder turbo diesel engine, built from 04/1996 to 07/2009 runout.
- Toyota Prado 120, 150 Series, KDJ120, KDJ150, fitted with the 1KDFTV 3.0 litre 4 cylinder Common Rail D4D turbo diesel engine, built from 08/2006 onwards.
NOTE: This water pump is used on KUN Hilux when you have installed the upgraded 2 piece water pump and rear cover/housing.
It will not suit an unmodified KUN Hilux with the single piece water pump and rear cover/housing as installed when new. See information below
It suits Prado and Surf as described above, and is used when your pump is worn or leaky but your housing/rear cover is in good serviceable condition.
